特點及優勢
-
高效能，強大連接能力
-
固定無線寬頻
-
最後一哩固定式無線接取
-
專為嚴苛環境設計
-
郊外、農村、大型戶外活動等欠缺網路服務或需要無線行動網路服務等地區
高效能
- 新一代5G NR(sub-6G)移動通訊模組*1
- 具備各項進階網路功能，可提供路由模式及IP Pass-Through模式
優化的雙極化MIMO天線
- 滿足大頻寬與遠距離通訊需求
虛擬私人網路 (VPN)
- IPSec, OpenVPN, GRE, PPTP, L2TP
中央監控管理系統
- CWMP(TR-069)
- Billion CMS
專為嚴苛環境設計
- 採用工業級元件搭配IP67等級外殼防水防塵外殼保護
- 靈巧強固的安裝套件設計不受架設環境限制
- 抗突波和靜電防護設計可有效預防雷擊或靜電突波
靈巧簡潔的設計
- 支援乙太網路供電(PoE)(Power over Ethernet)
- 單人即可輕鬆安裝
產品包裝含 PoE 供電器及安裝套件
規格
5G NR (sub-6G)移動通訊
- Embedded high performance 5G NR(sub-6G) module*1
- Embedded dual-polarized MIMO antenna
內建5G NR(sub-6G)模組
- Frequency bands and data rare depend on equipped 5G NR(sub-6G) module*1
網路協議與功能
-
IPv4, IPv6, IPv4/ IPv6 dual stack*2
- Dual APN*3
- Keep Alive
- IP Pass-Through
- NAT, Virtual Server and DMZ
- Static Routing, Dynamic Routing (RIP-1/2, OSPF, BGP)
- SNTP, DNS relay and DDNS
- Universal Plug & Play (UPnP)
-
Supports DHCP server/ client
防火牆
-
Built-in NAT firewall
-
Stateful Packet Inspection (SPI)
-
Prevents DoS attacks including Land Attack, Ping of Death, etc.
-
Access Control
-
IP Filtering, MAC Filtering, URL Filtering
- VPN pass-through
虛擬私人網路 (VPN)
- IPSec
- PPTP
- L2TP
- GRE
- OpenVPN
全球導航衛星系統 (GNSS) *2
- Embedded multi-GNSS engine for GPS or GLONASS system
設備管理系統
- Password protection for system management
- Web-based GUI for remote and local management
- Firmware upgrade and configuration data upload and download via Web GUI
- TR-069(CWMP)*2, Billion CMS*2, SNMP
- 5G NR Usage Allowance
- Syslog monitoring
- Physical layer/protocol diagnostic test tool
硬體規格
實體介面
- One(1) Gigabit Ethernet Interfaces with passive PoE PD
- One(1) Mini-SIM(2FF) slot (for the SIM from Telco/ISP)
- Reset Button
- LED Indicators: Power/Boot, LAN(PoE), Internet, Signal Strength, and GNSS*2
產品規格
- Dimensions: 257mm x 227 mm x 91mm (8.5" x 7.5" x 3.0")
- Weight: 1.81kg (4lbs)
- IP-67 grade enclosure
工作環境溫度
- Operating: -40°C to 60°C (-40°F to 140°F)
抗突波與靜電保護
- Surge Protection: K.21 common mode ±6KV
- ESD Protection: Contact: ±8KV / Air: ±15KV
